Početna Hardware Široki formati KIP 940

KIP 940

  • Proizvodna brzina za štampu širokog formata, crno-bijelu i u koloru, je između 325 i 390 kvadratnih metara na sat
  • LED sistem izlazne rezolucije 600 x 2400 dpi; CMYK suhi tonerski sistem za proizvodnju UV-otpornih i vodootpornih slika
  • Raznovrsnost rukovanja medijima: standardne 3 ladice za rolne i 1 ručni zaobilazni uvlakač za pojedinačne listove
  • Širok opseg odobrenih standardnih i specijalnih medija za unutrašnju i vanjsku upotrebu
  • Raspon softverskih aplikacija za tehničku dokumentaciju i proizvodnju grafičkih materijala u boji; integracija profesionalnog Grafičkog RIP softvera i alat za pregled standardnih troškova
  • Napredne opcije za završnu obradu za korisnike koji imaju zahtjeve u pogledu slaganja, sklapanja i automatskog rezanja; nadogradiv sistem s profesionalnim skenerima za stanice za kopiranje
Zatražite ponudu

Osobine

Osobine

KIP 940

Kad tražimo kvalitetu štampanja bilo u tehničkom, grafičkom ili uredskom okruženju, sa svojom preciznošću i izražajnim bojama zadivit će nas KIP 940, kolor i c/b sistem za štampanje velikog formata. Uređaj za štampanje širokog formata ima visoko produktivan ispis u jednom prolazu i predstavlja sveobuhvatno rješenje za razne štampane aplikacije velikog formata u rasponu od arhitektonskih, inženjerskih i građevinskih dokumenata do mapa, postera, znakova i plakata. Uz KIP 940 jednostavno nema potrebe da se traži kompromis za kvalitet, performanse i pouzdanost.

Specifikacije & Preuzimanje

Specifikacije & Preuzimanje
General
Description High production colour and b&w wide format printing system
Type Electrophotography (LED) with organic photoconductor (OPC) and closed toner system
Speed Up to 390 sq. m per hour in b&w – 325 sq. m per hour in colour
Warm up time Less than 6 minutes from power on
Configurations Printer or multifunction system (print/copy/scan)
Toner Four colour (CMYK), dry toner. Printed images are UV lightfast and waterproof
Electrical requirements 220 – 240 V, 50/60 Hz, 20 A
Power consumption Standby: 0.8 kW, Printing: 2.0 kW, Sleep Mode: 10 W
Dimensions 1,376 mm (w) x 790 mm (d) x 1,450 mm (h)
Weight 540 kg
Power consumption 3.0 kWh (printing), 1.0 kWh (standby)
Acoustic noise < 65 db (printing), < 55 db (standby)
Room temperature 10 – 32°C
Printer
Print resolution 600 x 2,400 dpi
Paper capacity 418 sq. m 3 rolls + cut sheet bypass
Output sizes width (roll media) 297 mm – 914 mm
Output sizes length (roll media) 210 mm minimum, 39 m maximum
Paper weight (roll media) Bond: 164 – 150 gsm, Vellum: 80 – 95 gsm, Film: 75 micron, Gloss: 120 gsm
Multi sheet bypass Automatically feeds up to 50 sheets of 75 gsm bond / Maximum sheet size 420 mm x 594 mm / Minimum sheet size 420 mm x 297 mm
Single sheet bypass Up to 120 gsm bond / Maximum sheet size 914 mm x 594 mm / Minimum sheet size 420 mm x 297 mm
Media types Bond, translucent bond, film, double matte, double matte, clear film, weather proof banner film, waterproof bond, film white opaque adhesive back/6 mil, film clear adhesive back, Blue Back, bright fluorescent bond, (yellow, orange, green, blue), fusion banner media
Controller
Type Embedded with Windows 7 CPU: Quad Core
Memory 3 GB
Compatible file formats Raster colour: TIFF, JPG, JPG2000, PNG, BMP, GIF, TGA, RLE/RLC Vector colour/b&w: HPGL, HPGL/2, HP-RTL, Postscript (PS/EPS), Adobe PDF, Autodesk DWF, Multipage PDF & DWF Raster b&w: TIFF Group 3 & 4, CALS Group 4, Grayscale TIFF, CIT/TG4 Vector b&w: Calcomp 906/907
Accessories
  KIP 940 Auto stacker
  KIP 2300 CCD scan system
  KIPFold 2000

  • The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
  • Some of the product illustrations contain optional accessories.
  • Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
  • Konica Minolta does not warrant that all specifications mentioned will be error-free.
  • Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
  • All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Preuzmite brošuru o proizvodu odmah kako biste imali sve informacije pri ruci.

KIP 940 brošura
